De Imecar Lithium 12,8V/200Ah LiFePO4 accu is gebaseerd op Lithium-ijzerfosfaat LFP technologie, de veiligste onder lithium-ion accutypes.

General data

• ISO 26262 rated components and design
• ASIL C / EN 61508 SIL 2 possible
• Self-test and redundancy in safety critical measurement circuits
• Open circuit detection
• High frequency sampling of current at 100 mS allows optimal detection of pulses
• Powerful and intelligent dissipative balancing
• Individual cell voltage measurement accuracy to within ±1.6 mV at 25 °C
• Optimized low power consumption mode
• ±1 °C accuracy in temperature measurement
• State-of-the-art algorithms for estimation of SOC
• Advanced SOH algorithm
• Advanced SOP algorithm (State of Power)
• Suitable for multi-string systems with monitoring on single-string and full system level
• Multi-level short circuit protection on system level
• Dynamic charger control algorithms
• Designed according ECE R10, UN38.3, ECE R100
• Scalable system with any number of Battery Packs
• High energy and performance density › Easy system connectivity / ready-to-install
• Excellent price-performane ratio
• Liquid cooling for even temperature distribution
• Compact and lightweight solution
• Long service life due to active and passive thermal management
• Exceptionally robust, maintenance-free operation

Electrical data 210M12L

• Cell connection in module: 2p4s
• Battery Capac: 210 Ah
• Energy: 2.6 kWh
• Technology: Li-Ion LFP
• Nominal voltage: 12.8 V
• Voltage (max.): 14.4 V
• Voltage (min.): 11.2 V
• Discharging power max. (10s)*: 3000 W
• Charging power max. (10s)*: 1000 W
• Continuous power (RMS) < 15 min*: 1200 W
• Continuous power (RMS) > 15 min*: 1000 W
• Power consumption in standby mode: 5 W
• Cycle life**: 2,000 – 10,000 cycles

Mechanical data

• Cooling type: Natual
• Cooling Operating temperature range: -25 to 60 °C
• Recommended operating temperature: 15 to 35 °C
• Protection classes: Ip21
• Weight (incl. contactor box) typical***: 25 kg
• Dimension (L x W x H) in mm (nominal): 205 x 377 x 282
