Specifications

• Nominal Voltage: 6V
• Nominal capacity @20 hour rate: 220Ah
• Capacity at 25°C:
  • 10 hour rate: 200Ah
  • 5 hour rate: 180Ah
  • 1 hour rate: 125Ah
• Shelf time @20°C up to 70%: 9 months
• Internal resistance (at 1 KHz): approx. 2,7 mΩ

Dimensions

• Dimensions LxWxH (T) in mm: 260 x 180 x 245
• Weight: 30,2kg (±2%)
• Separator: AGM, Glass Matt
• Case and cover: ABS
• Terminal: M8 Bolt
• Torque setting (recommended): M8: 10 Nm
• Maximum allowable torque value: M8: 12 Nm

Charging

• Operating temperature for (dis)charge: -15°C to + 40°C
• Charging Voltage cycle use 7,2 to 7,45 Volt
• Float charge Voltage 6,8 to 6,9 Volt
• Charging current, minimum 25A – maximum 35A
